Gradient flow formulation and second order numerical method for motion by mean curvature and contact line dynamics on rough surface

  • Yuan Gao

    Duke University, Durham, USA
  • Jian-Guo Liu

    Duke University, Durham, USA
Gradient flow formulation and second order numerical method for motion by mean curvature and contact line dynamics on rough surface cover
Download PDF

This article is published open access under our Subscribe to Open model.

Abstract

We study the dynamics of a droplet moving on an inclined rough surface in the absence of inertial and viscous stress effects. In this case, the dynamics of the droplet is a purely geometric motion in terms of the wetting domain and the capillary surface. Using a single graph representation, we interpret this geometric motion as a gradient flow on a manifold. We propose unconditionally stable first/second order numerical schemes to simulate this geometric motion of the droplet, which is described using motion by mean curvature coupled with moving contact lines. The schemes are based on (i) explicit moving boundaries, which decouple the dynamic updates of the contact lines and the capillary surface, (ii) an arbitrary Lagrangian–Eulerian method on moving grids and (iii) a predictor-corrector method with a nonlinear elliptic solver up to second order accuracy. For the case of quasi-static dynamics with continuous spatial variable in the numerical schemes, we prove the stability and convergence of the first/second order numerical schemes. To demonstrate the accuracy and long-time validation of the proposed schemes, several challenging computational examples – including breathing droplets, droplets on inhomogeneous rough surfaces and quasi-static Kelvin pendant droplets – are constructed and compared with exact solutions to quasi-static dynamics obtained by desingularized differential-algebraic system of equations (DAEs).

Cite this article

Yuan Gao, Jian-Guo Liu, Gradient flow formulation and second order numerical method for motion by mean curvature and contact line dynamics on rough surface. Interfaces Free Bound. 23 (2021), no. 1, pp. 103–158

DOI 10.4171/IFB/451
